Big Toroids
Product
Big Toroids
Large Toroids
- Available application
- Reactor in inverter for air Reactor in inverter for air
- Reactor of Solar Power Supply
- Line Reactor for Motor Drive.
- Inductor of UPS
- Big Power Supply ( >4kW)
- Advantage
- Air Cooling effect
- No leakage flux
- Effective magnetic characteristics.
design tool
